FortiGate 700G

Բնութագրեր

Hardware Accelerated GE RJ45 Interfaces - 16 Hardware Accelerated GE SFP Slots - 8 Hardware Accelerated 10GE SFP+ /GE SFP Slots - 4 Hardware Accelerated 25GE SFP28/ 10GE SFP+ Ultra Low Latency Slots - 4 GE RJ45 MGMT/HA Ports - 2 USB Ports - 2 RJ45 Console Port - 1 Included Transceivers - 2x SFP (SX 1 GE) IPS Throughput 2 - 14 Gbps NGFW Throughput 2, 4 - 11.5 Gbps Threat Protection Throughput 2, 5 - 10.5 Gbps IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) - 139/137.5/70 Gbps IPv6 Firewall Throughput (1518 / 512 / 64 byte, UDP) - 139/137.5/70 Gbps Firewall Latency (64 byte, UDP) - 4.12 μs / 2.5 μs Firewall Throughput (Packet per Second) - 105 Mpps Concurrent Sessions (TCP) - 8 Million New Sessions/Second (TCP) - 550 000 Firewall Policies - 30 000 IPsec VPN Throughput (512 byte) 1 - 55 Gbps Gateway-to-Gateway IPsec VPN Tunnels - 2 000 Client-to-Gateway IPsec VPN Tunnels - 50 000 SSL-VPN Throughput - 4.3 Gbps Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) - 10 000 SSL Inspection Throughput (IPS, avg. HTTPS) 3 - 9 Gbps SSL Inspection CPS (IPS, avg. HTTPS) 3 - 7 500 SSL Inspection Concurrent Session (IPS, avg. HTTPS) 3 - 840 000 Application Control Throughput (HTTP 64K) 2 - 32 Gbps CAPWAP Throughput (HTTP 64K) - 64.5 Gbps Virtual Domains (Default / Maximum) - 10/50 Maximum Number of FortiSwitches Supported - 128 Maximum Number of FortiAPs (Total / Tunnel) - 1024/512 Maximum Number of FortiTokens - 5 000 High Availability Configurations - Active-Active, Active-Passive, Clustering Operating Altitude Up to 10 000 ft (3048 m)

Hardware Accelerated GE RJ45 Interfaces - 16
Hardware Accelerated GE SFP Slots - 8
Hardware Accelerated 10GE SFP+ /GE SFP Slots - 4
Hardware Accelerated 25GE SFP28/ 10GE SFP+ Ultra Low Latency
Slots - 4
GE RJ45 MGMT/HA Ports - 2
USB Ports - 2
RJ45 Console Port - 1
Included Transceivers - 2x SFP (SX 1 GE)
IPS Throughput 2 - 14 Gbps
NGFW Throughput 2, 4 - 11.5 Gbps
Threat Protection Throughput 2, 5 - 10.5 Gbps
IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) -
139/137.5/70 Gbps
IPv6 Firewall Throughput
(1518 / 512 / 64 byte, UDP) - 139/137.5/70 Gbps
Firewall Latency (64 byte, UDP) - 4.12 μs / 2.5 μs
Firewall Throughput (Packet per Second) - 105 Mpps
Concurrent Sessions (TCP) - 8 Million
New Sessions/Second (TCP) - 550 000
Firewall Policies - 30 000
IPsec VPN Throughput (512 byte) 1 - 55 Gbps
Gateway-to-Gateway IPsec VPN Tunnels - 2 000
Client-to-Gateway IPsec VPN Tunnels - 50 000
SSL-VPN Throughput - 4.3 Gbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)
- 10 000
SSL Inspection Throughput (IPS, avg. HTTPS) 3 - 9 Gbps
SSL Inspection CPS (IPS, avg. HTTPS) 3 - 7 500
SSL Inspection Concurrent Session (IPS, avg. HTTPS) 3 - 840
000
Application Control Throughput (HTTP 64K) 2 - 32 Gbps
CAPWAP Throughput (HTTP 64K) - 64.5 Gbps
Virtual Domains (Default / Maximum) - 10/50
Maximum Number of FortiSwitches Supported - 128
Maximum Number of FortiAPs (Total / Tunnel) - 1024/512
Maximum Number of FortiTokens - 5 000
High Availability Configurations - Active-Active,
Active-Passive, Clustering
Operating Altitude Up to 10 000 ft (3048 m)
